KONICA JAPAN AeroScan CDlite

Here are the detailed technical specifications and features for the Konica Minolta AeroScan CD Elite (CD E-lite) Color Doppler Ultrasound System:

Imaging Modes & Performance

• Scanning Modes: Electronic Convex, Linear, Phased Array, and Convex Volume (for 3D/4D).

• Imaging Formats: B, Dual B, Quad B, THI (Tissue Harmonic Imaging), M-mode, Color Doppler, PDI/DPDI (Power Doppler Imaging), PW Doppler, CW Doppler, TDI (Tissue Doppler Imaging), HPRF, Dual-Live, Duplex, and Triplex modes.

• Probe Frequency Range: Broad range spanning $1\text{–}17\text{ MHz}$ (probe-dependent).

• Scanning Depth: $1\text{–}45\text{ cm}$.

Advanced Technology & Image Processing

• eBeam (Digital Multi-Beam Forming): Advanced processing algorithm supporting 8 parallel beam processing for highly enhanced frame rates and spatial resolution.

• TAI (Tissue Adaptive Imaging): Automatically adjusts B-mode and Color parameters based on real-time tissue interaction for automated, consistent scanning quality.

• eHI (Harmonic Imaging): Employs pulse inversion/reverse wave processing to maximize the harmonic signal, dramatically reducing artifacts and refining contrast resolution.

• eSRI (Speckle Reduction Imaging): Adaptive noise suppression that completely eliminates speckles to maximize signal-to-noise ratio and optimize boundaries.

• eVIEW (Adaptive Compound Imaging): Utilizes multi-angle spatial compounding to enhance boundary detection and structural detail.

• Workflow Integration: Features eOptimized (one-key image tuning) and eTouch (high-efficiency custom swipe gestures).

Specialist Features

• OB/GYN & 3D/4D: Supported by robust 4D volumetric data acquisition and e-Face (one-touch automated optimization for fetal face rendering). Optional transvaginal probes offer an ultra-wide $200^{\circ}$ Field of View (FOV).

• Cardiovascular: Anatomic M-Mode equipped with 3 independent cursors adjustable to any position or angle simultaneously (perfect for difficult fetal/adult cardiac alignments). Includes TDI (Tissue Doppler Imaging) for comprehensive myocardial velocity analysis.

• Interventional Radiology: Trapezoid Imaging expanding the linear probe viewing area by up to 30%. eNeedle Visualization technology optimizes the ultrasound path perpendicular to the needle shaft for brighter, highly accurate biopsy trajectories.

• Automated Measurements: Features Auto IMT (Intima-Media Thickness tracing) and Auto PW/CW Wave Trace for efficient cardiac and vascular workflow.

Hardware & Ergonomics

• Main Display: 21.5-inch High-Definition LED/LCD monitor mounted on a fully articulating, height-adjustable arm.

• Touch Console: 14-inch interactive touch screen with a $20^{\circ}$ adjustable tilt profile.

• Probe Ports: 5 Active Transducer Sockets providing simultaneous multi-specialty probe configurations.

• Storage & Architecture: High-speed 512 GB Solid State Drive (SSD) for lightning-fast archiving and boot-up speeds.

• Power Design: Grounded cart infrastructure with built-in battery backup for uninterrupted operations during unexpected power drops.

• Connectivity Sockets: Comprehensive peripheral mapping including HDMI, VGA, S-Video, USB 3.0, USB 2.0, and high-speed Ethernet ports.
